U.S. Motors HD1P4E Hostile Duty Three Phase TEFC Horizontal - Footed Motor Popular
Home / Nema & Tefc Motors / U.S. Motors HD1P4E Hostile Duty Three Phase TEFC Horizontal – Footed Motor Popular

U.S. Motors HD1P4E Hostile Duty Three Phase TEFC Horizontal – Footed Motor Popular

Original price was: $704.70.Current price is: $281.88.

For orders under $60.00, a shipping fee of $9.99 applies.
Fast delivery, satisfaction guaranteed.
Secure Payment.
SKU: SK0253041 Category: Tag:
Share

The U.S. Motors HD1P4E is a three-phase motor designed for hostile duty applications. It features a TEFC enclosure, which provides excellent protection in harsh environments. This motor is rated at one horsepower with a speed of nine hundred revolutions per minute, making it suitable for various industrial applications.

  • Voltage rating: 230/460 & 200/400
  • Continuous duty operation
  • Cast iron frame for durability

Product Highlights

The HD1P4E motor is engineered for reliability in challenging conditions. It is commonly used in pulp and paper plants, foundries, and other facilities that require a robust motor.

Product Information

Standard Information

  • Brand: U.S. Motors
  • Part Number: HD1P4E

Technical Specifications

  • Service Factor: 1.15
  • Poles: 8
  • Enclosure: TEFC
  • Phase: Three Phase
  • Hz: 50/60
  • Full Load Efficiency: 75.5%
  • Duty: Continuous Duty
  • Frame Material: Cast Iron
  • Frame Size: 182T
  • Mounting: Horizontal – Footed
  • Enclosure Designation: Totally Enclosed Fan Cooled
  • Full Load rpm: 720, 875
  • Full Load Amps: 4.5/2.3
  • Insulation: F
  • Weight: 80.0 LB
  • EAN or UPC: 786382132118
