Panduit LCAX2-12-E Pan-Lug Copper Compression Connectors – Lugs Affordable

Panduit LCAX2-12-E is a copper compression connector designed for reliable connections. It is suitable for #2 AWG wire and features a half-inch stud hole.

• One-hole design for ease of installation.
• Constructed from tin-plated copper for enhanced conductivity.
• Rated for 35 kV applications.

Product Highlights

This connector can handle power and grounding applications and is compatible with various wire types.

Product Information

Standard Information

• Catalog Number: LCAX2-12-E
• Manufacturer: Panduit

Technical Specifications

• Material: Tin-Plated Copper
• Stud Size: 0.5 inches
• Conductor Size: #2 AWG
• Temperature Rating: 90 degrees Celsius
• Voltage Rating: 35 kV
• Special Features: Consult cable manufacturer for voltage stress relief instructions with applications greater than two thousand volts
• Standard: UL listed to 486A-486B File #E52164 and CSA certified C22.2 No. 65-13
• Country of Origin: Mexico
