Leeson 113581.00 AC Motor 1/2 hp 3450 rpm Single Phase 115/208-230 Voltage Rating Top Rated
Home / Single Phase Motors / Leeson 113581.00 AC Motor 1/2 hp 3450 rpm Single Phase 115/208-230 Voltage Rating Top Rated

Leeson 113581.00 AC Motor 1/2 hp 3450 rpm Single Phase 115/208-230 Voltage Rating Top Rated

Original price was: $541.53.Current price is: $216.61.

For orders under $60.00, a shipping fee of $9.99 applies.
Fast delivery, satisfaction guaranteed.
Secure Payment.
SKU: SK0278691 Category: Tag:
Share

The Leeson 113581.00 is a reliable AC motor designed for general purpose applications. This motor operates at half a horsepower and reaches speeds of three thousand four hundred fifty revolutions per minute. It is suitable for single phase installations and supports a voltage rating of one hundred fifteen to two hundred eight volts, or two hundred thirty volts. The motor features a rigid base mount for stability during operation and comes with a totally enclosed fan-cooled design, making it durable for various environments.

  • Power: 1/2 hp
  • Speed: 3450 rpm
  • Voltage: 115/208-230

Product Highlights

Ideal for HVAC, plumbing, and other trade applications that require efficiency and dependability.

Product Information

Standard Information

  • Brand: Leeson
  • MPN: 113581.00

Technical Specifications

  • Frequency: 60 Hz
  • Efficiency Group: 63 %
  • Mounting: Rigid Base
  • Motor Application: General Purpose
  • Full Load Amps: 7.6/4-3.8
  • Poles: 2
  • Phase: Single Phase
  • Rotation: Selective CCW
  • Enclosure Designation: Totally Enclosed Fan Cooled
  • RPM: 3450
  • Drive End Bearing: 6205
  • Frame: 56C
  • Frame Material: Rolled Steel
  • Enclosure: TEFC
  • Insulation: F
  • Voltage Rating: 115/208-230
  • Weight: 28.0 LB
  • EAN or UPC: 691720012062
