Garlock 24736-0371 Model 59 Single Lip Seal Deal

The Garlock Model 59 Single Lip Seal with MPN 24736-0371 is designed for heavy-duty applications. This seal features an assembled design with a spring for enhanced functionality. It is suitable for environments with a temperature range of minus forty degrees Fahrenheit to two hundred degrees Fahrenheit.

• Single lip with spring design
• Housing bore diameter of twenty-two inches
• Maximum pressure of seven psi

Product Highlights

This seal is ideal for applications requiring moderate to severe service and can handle a surface speed of up to five thousand feet per minute.

Product Information

Standard Information

• Brand: Garlock
• Part Number: 101081058

Technical Specifications

• Seal Design: Assembled Design
• Lip Type: Single Lip w/Spring
• Temperature Range [Max]: 200 °F
• Temperature Range [Min]: -40 °F
• Housing Bore Dia.: 22 in
• Shaft Dia.: 20.5 in
• Case Construction: Steel Case w/Inner Case
• Construction: Model 59
• Seal Application: Heavy Duty, Moderate to Severe Service
• Lip Material: Mill-Right® N
• Spring Material: Stainless Steel Finger
• Lip Style: Internal
• Misalignment & Runout: 0.093@2500
• Pressure [Max]: 7 psi
• Surface Speed [Max]: 5,000 ft/min
• Weight: 5.44 LB
• EAN or UPC: 717744155315
